Power dump cart UM205
Power Dump Cart UM205
Heavy-Duty Electric Garden Dump Truck For Materials Handling
| Model Number | UM205A | UM205B |
|---|---|---|
| Product size | 1470x690x940mm | 1695×970×800mm |
| Lifting angle | 45 | 65 |
| Motor in driving | 36v 800w | 24v/1500w |
| Lifting time | 15s | 15s |
| Controller | 36v 70a | 24v/150a |
| Pump max pressure | 20mpa | 20mpa |
| Max speed | 5~10km/h | 24v/800w |
| Working noise | 40~50 db | 40~50 db |
| Tray size | 1110 x 690 x 380 x 611mm | 1310 x 970 x 380 x 611mm |
| Max loading capacity | 500kg | 350kg |
| Motor in lifting | 800w | 24v/800w |
| Battery | 3x12v 55ah | 24v/75a ×2 |
| Charger time | 10hours | 10hours |
| Max working temperature | ≤80oc | ≤80oc |
| Max Climbing capability | 6 | 6 |
| GW/NW | 300kg/280kg | 210kg |
